AM Areal confocal 3D microsensor
Product Features
● New generation fully autonomous confocal 3D microscopic sensor/probe
● Surface scanning, cross-scale, true color, fast imaging
 | High Efficiency:Array imaging, faster speed High Flexibility:Range, accuracy, and speed can be flexibly configured according to the application scenario High Adaptability:Adaptable to smooth surfaces, complex surfaces, highly reflective materials, and transparent materials Easy Integration:Open SDK, small size Low Maintenance Cost:Remote parameter adjustment, remote SDK updates, stable and reliable LED light source with long lifespan |
| Demonstration Diagram |
Product Introduction
Cross-scale, cross-platform applicability | ==> | Desktop 3D microscope, non-contact roughness meter, desktop 3D profiler, automated 3D measurement equipment, 3D AOI | ||
Traditional Technology Products |
| Application Types | ||
①Super-depth microscope ②Digital 3D microscope ③Laser confocal 3D microscope ④White light interferometer | <==substitute | applications==> | ①Defect detection ②Critical dimension measurement ③Surface profile analysis ④Roughness detection ⑤Transparent film thickness detection ... | |
Model Name | AM 100 (Large Range) | AM 10 (High Precision) | AM 1 (Ultra-high Precision) | ||||||||||||||||||||||||||||||||||||||||
Principle | wide-field confocal | wide-field confocal | wide-field confocal | ||||||||||||||||||||||||||||||||||||||||
Axial Scanning Device | Motor | PZT+motor | PZT+motor | ||||||||||||||||||||||||||||||||||||||||
Light Source | LED | LED | LED | ||||||||||||||||||||||||||||||||||||||||
Axial accuracy (μm) | 0.1 | 0.01 (PZT), 0.1 (Motor) | 0.001 (PZT), 0.1 (Motor) | ||||||||||||||||||||||||||||||||||||||||
Range（μm） | 30000 | 500 (PZT), 30000 (Motor) | 400 (PZT), 30000 (Motor) | ||||||||||||||||||||||||||||||||||||||||
Typical Imaging Time（s） | 3 ① | 3 (Motor) ~ 7 (PZT) | 3 (Motor) ~ 7 (PZT) | ||||||||||||||||||||||||||||||||||||||||
Size (HxWxD) mm | 490 x 200 x 185 | 510 x 200 x 185 | 510 x 200 x 185 | ||||||||||||||||||||||||||||||||||||||||
Weight (kg) | 10 | 10 | 10 | ||||||||||||||||||||||||||||||||||||||||
Output | 3D point cloud, 2D color map | 3D point cloud, 2D color map | 3D point cloud, 2D color map | ||||||||||||||||||||||||||||||||||||||||
Objective③ | 10X | 20X | 50X | ||||||||||||||||||||||||||||||||||||||||
Optional Objective④ |
| ||||||||||||||||||||||||||||||||||||||||||
Note | ①Limited by the objective lens working distance, the maximum range is 30mm; motor stroke 100mm; ②Calculated based on 100 axial positions; ③Sensor weight does not include Z motor, motor weight 6kg; ④The sensor does not include an objective lens as standard; choose an objective lens according to your needs ⑤AM10 and AM1 do not include a Z motor as standard; a 100mm motor can be optionally added as needed | ||||||||||||||||||||||||||||||||||||||||||
Solar cell silicon suede pyramid, grid line measurement
PV application: Solar cell silicon suede pyramid, grid line measurement
Back bore hole depth measurement, up to 8mm deep hole
High-end PCB manufacturing:back drilling Application: Back bore hole depth measurement, up to 8mm deep hole
High-end IC carrier bore hole depth measurement
High-end PCB manufacturing:Laser drilling of IC substrate application: High-end IC carrier bore hole depth measurement
Measurement of the depth and width of the cutting groove after the wafer laser cutting
OSAT (Front-End) application： Measurement of the depth and width of the cutting groove after the wafer laser cutting
